产品描述
Product Description
SIZE:20x20x6mm
CONSTRUCTION:Glass Fiber reinforced plastic; Impeller and housing PBT are UL 94V-0 rating Cover is stainless steel
OPERATING TEMPERATURE:CycleSeal bearing -10℃ to +70℃
INSULATION RESISTANCE:10meg Ohm min, at 500 VDC(between frame and terminal)
DIELECTRIC STRENGTH:5mA max, at 500 VAC 60Hz one minute(between frame and terminal)
FUNCTION OPTIONS:FG,RD, PWM,Auto Restart, Polarity Protection
尺寸图
Dimensions Drawing
特征曲线
Characteristic Curves
规格参数
Specifications
SIZE (mm) | MODEL | Bearing(X) | Voltage | Testing Current | SPEED (RPM) | AIR FLOW (CFM) | PRESSURE (mmAq) | NOISE (dBA) | W (g) |
B8020 | YBH8020X12 | C or B | 12 | 0.36 | 4000 | 17.23 | 23.88 | 40.80 | 54 |
YBM8020X12 | 0.24 | 3000 | 12.99 | 11.84 | 30.60 | 54 | |||
YBL8020X12 | 0.10 | 2000 | 8.80 | 4.56 | 20.40 | 54 | |||
YBH8020X24 | 24 | 0.20 | 4000 | 17.23 | 23.88 | 40.80 | 54 | ||
YBM8020X24 | 0.13 | 3000 | 12.99 | 11.84 | 30.60 | 54 | |||
YBL8020X24 | 0.06 | 2000 | 8.80 | 4.56 | 20.40 | 54 |
1.Specifications subject to change without notiec;
2.Design and provide products according to client’s requirements.
